Grade Superblack – Reinforced Barrier Product

Blue Shield SuperBlack

Concrete Underlayment

Blue Shield Super Black is a concrete underlayment that provides a high level of moisture protection.

Product Features

  • Supplied in 96” wide rolls, this product is easily rolled out over the top of graded and compacted soil
  • The weight and quality of the product allows it to lay flat
  • Standard seaming tapes are used to overlap (6”) and seam the product
  • Economical and easy to install
  • When used underneath concrete slabs, the product provides a high level of moisture protection
  • Reinforced for enhanced durability on the job site
Clear
SKU: N/A Category:

Description

  • Product Literature
  • Composition

    SuperBlack features high grade polymer coatings and fiberglass reinforcement for added durability.

    This product is offered in 96” x 250’ rolls.

    Physical Properties:

    Water Vapor Permanence < 0.30 perms
    Water Resistance = 48 hours
    Tensile Strength

    • MD = 71 lb/in
    • CD = 41 lb/in

    Custom sizing is available, contact Holland for more information.

  • Product Applications

    CONCRETE UNDERLAYMENT

    It is advised to inspect the product, once applied, to ensure no punctures or tears have occurred during installation. After final inspection, concrete should be poured as soon as possible.

    SuperBlack is not recommended for vertical waterproofing applications. It is specially designed for underslab applications and can be used for the control of radon emissions.

    Follow installation procedures outlined in ASTM E-1643.

    MOISTURE BARRIER

    Blue Shield SuperBlack is a reinforced, moisture barrier that is used underneath concrete slabs for moisture protection. Moisture protection is critical for underneath concrete slabs. Without protection, trapped moisture vapor can travel through concrete and cause significant damage and failure to flooring.



Additional information

Standard Sizes

48" x 250' (1000 sq. ft), 96" x 250' (2000 sq. ft)

Standard Size

SKU PRODUCT SIZE Rolls per Pallet Roll Weight (lbs) Pallet Weight (lbs) Core Specification Default Wind Direction Lead Time
SB48x240 48″ x 250′ (1000 sq. ft) 42 40 1710 2″ ID Core Scrim Side Out 8 Business Days
SB96x250 96″ x 250′ (2000 sq. ft) 30 80 2430 3″ ID Core Scrim Side Out 8 Business Days
